The Carlson Cadnet Software

Alternative Views:

List Price: $1,595.00
Our Price: $1,595.00

Product Code: 2020.019.001


Carlson CADnet software

Carlson CADnet

First released as a separate module, Carlson CADnet allows users to create CAD from non-CAD documents such as PDFs, raster images, and paper plans. CAD text can also be generated from raster images with CADnet’s built-in Optical Character Recognition (OCR).

CADnet gives users the ability to import BIM models (doors, windows, walls, roofs, etc.) and bring them into CAD as CAD entities; plus, CADnet includes a routine to export surfaces into BIM.

Carlson CADnet supports AutoCAD® and comes with IntelliCAD® built-in. This is in addition to working on legacy AutoCAD versions.

Developed for more than 10 years within Takeoff, Carlson’s popular site estimating and data prep software,Turn non-CAD into CAD with CADnet Carlson CADnet joins with Carlson GeoTech and Carlson Trench to provide customers the flexibility to obtain just the software they need at an affordable price. The three new modules can also be paired with Carlson Construction to form the all new Carlson Takeoff Suite, replacing the non-OEM version of Takeoff. (Note: the Carlson Takeoff R-series with built-in AutoCAD remains the same.)

“These modules serve to answer the specific needs of geotechnicians, civil engineers, and construction professionals who may not have required all of Takeoff’s many capabilities,” says Todd Carlson, product manager for Takeoff.

Key Capabilities:

  • Import PDF Files
  • Import BIM using IFC Files
  • Export Carlson surface to BIM using IFC Files
  • Convert Raster images to vector CAD entities
  • Modify Raster images using cut, copy, remove speckles and thicken commands
  • Create CAD entities from the raster image using Trace functions and raster snaps
  • Create text entities extracted from the raster images
  • Digitize from paper plans or on-screen images
  • Full set of digitize routines for points, polylines, areas, contours, profiles, sections and end-areas
  • General

    • Built on AutoCAD and IntelliCAD

      Carlson Survey will run in AutoCAD® as well as AutoCAD® Map, Land Desktop and Civil3D and also on IntelliCAD.

    • Project Setup

      Flexible data storage methods

    • Drawing Cleanup

      Fix common drafting errors

    • Drafting Enchancements

      Handy tools for working in AutoCAD® such as Join Nearest, Shrinkwrap Entities, Polyline Utilities, Drawing Inspector, Layer Inspector and Twist Screen

    • Data Compatibility

      Supports industry standard LandXML and scores of specific data conversions


    • Import/Export

      User-defined import and export of point data along with conversions with specific other formats

    • Draw Points

      Draw points with settings for symbols, layers and styles

    • Point Groups

      Point group manager to define sets of point by filters

    • Coordinate File History

      Tracks all changes to points with report and undo functions

    • Fix Point Label Overlaps

      Finds point label overlaps with rule options to fix automatically

    • Point Tools

      Utilities for modify point labels such as move with leader, twist and resize
